Agricultural Subsoiler

Agricultural Subsoiler Specification

Tool Type
Subsoiler Shank

Shape
Rectangular frame with angled shank

Usage & Applications
Breaking soil compaction, enhancing water infiltration, promoting healthy crop growth

Noise Level
Low (implement only, depends on tractor)

Features
Rugged construction, adjustable depth, replaceable wear parts

Product Type
Subsoiler

General Use
Deep soil tillage and breaking hardpan for better root development

Capacity
1 row

Weight (kg)
Approx. 250 kg

Type
Agricultural Subsoiler

Drive Type
Tractor Driven

Power
55 HP and above required

Power Source
Tractor PTO

Transmission Type
PTO driven

Engine Type
Not applicable (Tractor Implement)

Start Method
Tractor operated

Tilling Scope
Up to 24 inches depth

Machine Speed
Matches tractor speed

Production Output
High soil penetration, up to 1 acre/hour (varies with soil and tractor)

Material
Metal

Dimension (L*W*H)
Approx. 2200 mm x 600 mm x 1200 mm

Color
Red

Warranty
1 Month

Maximum Working Depth
Up to 24 inch (600 mm)

Working Width
Approx. 500 mm (single tine)

Finishing
Paint coated for rust resistance

Frame Type
Heavy-duty, powder coated frame

Shank Material
High carbon, wear-resistant steel

Attachment
Three Point Linkage (Category II/III universal hitch)

Number of Tines/Shanks
1 to 3 (Single or multi-shank optional)

Depth Adjustment
Mechanically adjustable

Agricultural Subsoiler Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
500 Pieces Per Month

Delivery Time
4-5 Days

Main Domestic Market
All India

About Agricultural Subsoiler

We are a profound manufacturer of Agricultural Subsoiler in the market. This is a tillage tool that helps in improving growth in all crops where soil compaction is a problem. Agricultural Subsoiler is made using premium grade raw material and hi tech machinery at our unit in accordance with the industrial set standards.

Other Details
Usage : Agriculture Industry
Surface Treatment : Painted
Features : Durable,Corrosion Resistance

Superior Construction for Deep Tillage

Built with heavy-duty, powder-coated metal and high-carbon steel shanks, the subsoiler ensures lasting durability and optimal performance in challenging soils. Its design allows for single or multiple tines, catering to various agricultural requirements and maximizing soil penetration.

Flexible and Easy to Operate

This subsoiler features a mechanically adjustable depth controller and attaches via a Category II/III universal hitch, making it compatible with most 55 HP+ tractors. Depth can be precisely set to match specific field conditions and crop requirements without complex setup.

Designed for Enhanced Soil Health

By breaking compacted hardpan layers beneath the surface, the subsoiler improves air and water infiltration, promoting healthy crop growth and robust root development. This practice boosts yields and fertility in fields by allowing roots to access deeper nutrients and moisture.

FAQ's of Agricultural Subsoiler:

Q: How do I attach the subsoiler to my tractor?

A: The subsoiler uses a three-point linkage compatible with Category II and III universal hitches, making it easy to connect to most tractors with 55 HP or higher. Simply align the tractor's linkage arms with the implement's attachment points and secure with the provided pins.

Q: What is the primary benefit of using this subsoiler?

A: The main benefit is deep soil tillage-penetrating up to 24 inches-breaking up hardpan layers, enhancing water infiltration, and improving root development, which leads to healthier crops and increased yields.

Q: When should I use the subsoiler in my fields?

A: It's best to use the subsoiler before the primary planting season or after harvesting, when soils are not too wet or dry. This ensures maximum effectiveness in breaking compaction without damaging soil structure.

Q: Where is this subsoiler manufactured and available?

A: This subsoiler is manufactured in India and is available through manufacturers, suppliers, and wholesalers across the country. It's suitable for large and small-scale farms.

Q: What maintenance does the subsoiler require?

A: Routine checks should be performed on the tines and frame. Replace worn or damaged shanks, lubricate linkage points, and inspect for rust despite the paint coating to ensure reliable performance and longevity.

Q: How is the working depth set and adjusted?

A: The working depth is mechanically adjustable. You can set the desired tillage depth up to 24 inches by adjusting the depth control mechanism, ensuring adaptability to various soil and crop conditions.
